Texas InstrumentsLM139AJ/883ICMilitary Grade Electronic ComponentsLOW POWER LOW OFFSET VOLTAGE QUAD COMPARATORS
Prezentare
Find and request a quote for LM139AJ/883 from us. We are offering our customers a wide range of Texas Instruments.
Detalii produs
| Section | Attribute | Value |
|---|---|---|
| Physical | Case/Package | CDIP |
| Contact Plating | Tin , Lead | |
| Mount | Through Hole | |
| Number of Pins | 14 | |
| Technical | Common Mode Rejection Ratio | 60 dB |
| Input Bias Current | 1 nA | |
| Input Offset Voltage (Vos) | 2 mV | |
| Max Dual Supply Voltage | 15 V | |
| Max Operating Temperature | 125 °C | |
| Max Power Dissipation | 1.2 W | |
| Max Supply Voltage | 30 V | |
| Min Dual Supply Voltage | 2.5 V | |
| Min Operating Temperature | -55 °C | |
| Min Supply Voltage | 5 V | |
| Nominal Supply Current | 2 mA | |
| Number of Channels | 4 | |
| Number of Elements | 4 | |
| Output Current | 16 mA | |
| Power Dissipation | 1.2 W | |
| Power Supply Rejection Ratio (PSRR) | 60 dB | |
| Response Time | 5 µs | |
| Voltage Gain | 93.98 dB | |
| Compliance | Lead Free | Contains Lead |
| Radiation Hardening | No | |
| RoHS | Compliant |
